ZOV07D180K
MOV Metal Oxide Varistor Ø 7mm • VACrms= 11V • Prated= 0.02W • Energy10/1000 uS= 0.9 J
Overview
ZOV varistors are nonlinear 2-electrode semiconductor voltage-dependent resistors, which are designed for transient voltage suppression and surge energy absorption.
Features
- Large absorbing transient energy capability
- Very short response time
- Low Clamping ratio and no follow-on current
- High resistance Insulation Material prevents the electric arching to the adjacent devices
Specification
| Size | 7mm |
| Max Allowable ACrms Voltage (V) | 11V |
| Max Allowable DC Voltage (V) | 14V |
| Varistor Voltage @1mA (V) | 18V |
| Max Peak Current @8/20uS (A) | 250A |
| Max Energy 10/1000 uS (J) | 0.9 |
| Rated Power (W) | 0.02W |
| Typical Capacitance @ 1kHz (pF) | 2800F |
$0.04
Original: $0.12
-67%ZOV07D180K—
$0.12
$0.04Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
MOV Metal Oxide Varistor Ø 7mm • VACrms= 11V • Prated= 0.02W • Energy10/1000 uS= 0.9 J
Overview
ZOV varistors are nonlinear 2-electrode semiconductor voltage-dependent resistors, which are designed for transient voltage suppression and surge energy absorption.
Features
- Large absorbing transient energy capability
- Very short response time
- Low Clamping ratio and no follow-on current
- High resistance Insulation Material prevents the electric arching to the adjacent devices
Specification
| Size | 7mm |
| Max Allowable ACrms Voltage (V) | 11V |
| Max Allowable DC Voltage (V) | 14V |
| Varistor Voltage @1mA (V) | 18V |
| Max Peak Current @8/20uS (A) | 250A |
| Max Energy 10/1000 uS (J) | 0.9 |
| Rated Power (W) | 0.02W |
| Typical Capacitance @ 1kHz (pF) | 2800F |
