XY133-08ST
SIL Header Low Profile Polarized Locking Straight Type • 2.5mm • 8 way • Mates with : XY-133-08HT
Overview
Features
- JST Style 2.5mm Wire to Board Series
- Low Profile, Polarized, Locking 6.2mm Height, Straight Type
- Mates with XY-133-08HT
- Insulator Material : Nylon 66 (UL 94V-0)
- Contact Material : Brass
- Contact Plated : Tin Plated
Specification
| No. of Contacts | 8 |
| No. of Pins | 8 |
| Pin Plating | Tin Plated |
| Size | 2.5mm |
| Mating Style | Mates with : XY-133-08HT |
$0.02
Original: $0.08
-75%XY133-08ST—
$0.08
$0.02Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
SIL Header Low Profile Polarized Locking Straight Type • 2.5mm • 8 way • Mates with : XY-133-08HT
Overview
Features
- JST Style 2.5mm Wire to Board Series
- Low Profile, Polarized, Locking 6.2mm Height, Straight Type
- Mates with XY-133-08HT
- Insulator Material : Nylon 66 (UL 94V-0)
- Contact Material : Brass
- Contact Plated : Tin Plated
Specification
| No. of Contacts | 8 |
| No. of Pins | 8 |
| Pin Plating | Tin Plated |
| Size | 2.5mm |
| Mating Style | Mates with : XY-133-08HT |
