UNI-T UT302C+
Infrared Thermometer -32℃~1100℃ , D:S RATIO 20:1
Infrared Thermometer -32°C~1100°C
Overview
Set a start time and interval, device will auto
turn on at start time, perform a measurement,
then turn off, and repeat the procedure once for
every interval time. Interval range from 1 min to
96 hours, number of measurement and data
storage can be up to 99 sets.
Features
- 20:1 D:S ratio
- Adjustable emissivity 0.1~1.0
- ±1.5℃ temperature measurement accuracy
- User defined visual and audio alarm
- High contrast EBTN color display
- MAX/MIN/AVG/DIFF/Hold modes
- Dual lasers (UT302C+)
- Temperature recording up to 99 groups (UT302C+)
- Date/time display (UT302C+)
- Time scheduled measurement (UT302C+)
Specifications
| Specifications | UT302C+ |
| Temperature range | -32℃~1100℃ |
| -25.6℉~2012℉ | |
| Accuracy | ≥0℃: ±1.5℃ or ±1.5%; <0℃: ±(1.5℃+0.1℃/℃) |
| ≥32℉: ±3.0℉ or ±1.5%; <32℉: ±(3.0℉+0.1℉/℉) | |
| Repeatability | 0.7℃ or 0.7% (1.5℉ or 0.7%) |
| D:S ratio | 20:1 |
| Response time | 250ms |
| Emissivity | 0.1~1.0 (adjustable, stores 5 sets of preset values) |
| Spectral response | 8um~14um |
| Laser power | < 1mW |
| Features | |
| Auto power off | Yes |
| Low battery indication | Yes |
| LCD display | Color EBTN |
| High/low LED alarm | Yes |
| High/low audible alarm | Yes |
| Data hold/Lock measurement | Yes |
| ℃/℉ selection | Yes |
| MAX/MIN/AVG/DIFF mode | Yes |
| Data storage with date and time | 99 |
| Scheduled measurement | Yes |
| Backlight | Yes |
| Operating temperature | 0℃~50℃ (32℉~122℉) |
| Storage temperature | -20℃~60℃ (-4℉~140℉) |
| Operating humidity | <90%RH (non-condensing) |
| Drop test | 1m |
| Tripod mounting hole | Yes |
| General Characterisitics | |
| Power | 9V battery |
| Display | 35mm x 35mm |
| Product color | Red and grey |
| Product net weight | 310g |
| Product size | 172mm x 113.5mm x 53mm |
| Standard accessories | Battery, carrying bag |
| Standard individual packing | Gift box, blister, English manual |
| Standard quantity per carton | 10pcs |
| Standard carton measurement | 425mm x 335mm x 365mm |
| Standard carton gross weight | 6.65kg |
Downloads
Additional Information
| Device | Thermometer |
| Type | Infrared |
