TQ2-3V
Submini Telecom Relay • Form 2C • VCoil= 3V DC • IMax Switching= 1A • RCoil= 64Ω • PCB
Overview
Features
Polarized
Specification
| Model | TQ2-3V |
| Contact Form | Form 2C |
| Size Category | Submini |
| Size | 14x9x5mm |
| Termination | PCB |
| Coil Rated Voltage | 3V |
| AC/DC Voltage | DC |
| Max. Switching Current | 1A |
| Electrical Rating | 1A/30VDC |
| Coil Power | 140mW Power |
| Coil Resistance | 64Ω |
| Isolation Voltage | 1KV |
| Approvals | UL/CSA |
| Contact Material | Ag/Au clad |
| No. of Pins | 8 Pin(s) |
| No. of Poles | 2 Pole(s) |
Downloads
$3.49
TQ2-3V—
$3.49
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Submini Telecom Relay • Form 2C • VCoil= 3V DC • IMax Switching= 1A • RCoil= 64Ω • PCB
Overview
Features
Polarized
Specification
| Model | TQ2-3V |
| Contact Form | Form 2C |
| Size Category | Submini |
| Size | 14x9x5mm |
| Termination | PCB |
| Coil Rated Voltage | 3V |
| AC/DC Voltage | DC |
| Max. Switching Current | 1A |
| Electrical Rating | 1A/30VDC |
| Coil Power | 140mW Power |
| Coil Resistance | 64Ω |
| Isolation Voltage | 1KV |
| Approvals | UL/CSA |
| Contact Material | Ag/Au clad |
| No. of Pins | 8 Pin(s) |
| No. of Poles | 2 Pole(s) |
