SFV50-6
Circular Connector M16 Panel Male 3 Pole Rear Mount Back Screwed Solder Contacts IP40 270° *** 09-0315-00-05 ***
M16 Panel Male 3 Pole Circular Connector
Specifications
|
Number of Positions
|
5
|
|
Shell Size - Insert
|
M16
|
|
Mounting Type
|
Chassis Mount
|
|
Mounting Feature
|
Front Side Nut
|
|
Termination
|
Solder
|
|
Fastening Type
|
Threaded
|
|
Primary Material
|
Metal
|
|
Shell Material
|
Zinc Die Cast
|
|
Shell Finish
|
Nickel
|
|
Contact Finish - Mating
|
Silver
|
|
Ingress Protection
|
IP40
|
|
Material Flammability Rating
|
UL94
|
|
Operating Temperature
|
-40°C ~ 85°C
|
Downloads
Additional Information
| Device | Connector |
| Type | M16 | Panel | Male | 3 Pole | Circular |
| Highlights | Locking Type with threaded joint |
| Insulator Resistance | 1013Ω |
| Electrical Rating | 250VAC 5A |
| Degree of Protection | IP40 |
$2.12
Original: $7.07
-70%SFV50-6—
$7.07
$2.12Product Information
