SCK15154MSY
ø15mm Radial Power NTC Thermistor for Limiting Inrush Current with R25°C= 15Ω, I25°C= 4A, ±20% Tolerance
Overview
Features
- RoHS & Halogen Free (HF) compliant
- Radial lead resin coated
- High power rating
- Wide resistance range
- Cost effective
- Operating temperature range :
- Agency recognition: UL / cUL / TUV / CSA / CQC
Specification
| Size | ø15mm |
| Termination | Radial |
| Tolerance | ±20% |
| Tolerance Code | M |
| Max Steady State Current @25 degC | 4A |
| Zero Power Resistance @ 25 degC | 15Ω |
Downloads
$0.41
SCK15154MSY—
$0.41
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
ø15mm Radial Power NTC Thermistor for Limiting Inrush Current with R25°C= 15Ω, I25°C= 4A, ±20% Tolerance
Overview
Features
- RoHS & Halogen Free (HF) compliant
- Radial lead resin coated
- High power rating
- Wide resistance range
- Cost effective
- Operating temperature range :
- Agency recognition: UL / cUL / TUV / CSA / CQC
Specification
| Size | ø15mm |
| Termination | Radial |
| Tolerance | ±20% |
| Tolerance Code | M |
| Max Steady State Current @25 degC | 4A |
| Zero Power Resistance @ 25 degC | 15Ω |
