NF4-2M-24V
Medium Power Relay • Form 2D & 2C • VCoil= 24V DC • IMax Switching= 2A • RCoil= 1.2kΩ • PCB • Horizontal Case
Overview
Features
- Horizontal Case
Specification
| Contact Form | Form 2D & 2C |
| Size Category | Std size |
| Size | 30x24x11mm |
| Termination | PCB |
| Coil Rated Voltage | 24V |
| AC/DC Voltage | DC |
| Max. Switching Current | 2A |
| Electrical Rating | 2A/220VAC/DC |
| Coil Power | 480mW Power |
| Coil Resistance | 1.2kΩ |
| Isolation Voltage | 1KV |
| Approvals | UL/CSA |
| Contact Material | Ag |
| No. of Pins | 14 Pin(s) |
| No. of Poles | 4 Pole(s) |
Downloads
$21.18
NF4-2M-24V—
$21.18
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Medium Power Relay • Form 2D & 2C • VCoil= 24V DC • IMax Switching= 2A • RCoil= 1.2kΩ • PCB • Horizontal Case
Overview
Features
- Horizontal Case
Specification
| Contact Form | Form 2D & 2C |
| Size Category | Std size |
| Size | 30x24x11mm |
| Termination | PCB |
| Coil Rated Voltage | 24V |
| AC/DC Voltage | DC |
| Max. Switching Current | 2A |
| Electrical Rating | 2A/220VAC/DC |
| Coil Power | 480mW Power |
| Coil Resistance | 1.2kΩ |
| Isolation Voltage | 1KV |
| Approvals | UL/CSA |
| Contact Material | Ag |
| No. of Pins | 14 Pin(s) |
| No. of Poles | 4 Pole(s) |
