LMF1000-20B48
Metal Case Switch Mode Power Supply with Active PFC. Input: 90 ~ 264VAC/120 - 430VDC. Output 48VDC @ 21A + 5V @ 2A. Built-in Variable Speed DC Fan
Metal Case Switch Mode Power Supply
Feature
- Wide range Input voltage 90 - 264VAC or 120 - 370VDC
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +70℃
(Non-condensing) - High reliability, efficiency up to 94%
- Wide range of adjustable output voltage
- Output short circuit, over-current, over-voltage protection,
over-temperature protection - Support 3+1 parallel redundancy, current sharing
- Built-in active PFC function
- Operating up to 5000m altitude
- Fan speed automatic adjustable
- Safety according to IEC62368, ES/EN60601
Downloads
Additional Information
| Device | Power Supply |
| Type | Metal Case | Switch Mode |
| Input Voltage | 90 ~ 264VAC/120 - 430VDC |
| Output | 48VDC @ 21A + 5V @ 2A |
| Size | 190.0 x 127.0 x 40.5 mm |
$282.44
LMF1000-20B48—
$282.44
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Metal Case Switch Mode Power Supply with Active PFC. Input: 90 ~ 264VAC/120 - 430VDC. Output 48VDC @ 21A + 5V @ 2A. Built-in Variable Speed DC Fan
Metal Case Switch Mode Power Supply
Feature
- Wide range Input voltage 90 - 264VAC or 120 - 370VDC
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +70℃
(Non-condensing) - High reliability, efficiency up to 94%
- Wide range of adjustable output voltage
- Output short circuit, over-current, over-voltage protection,
over-temperature protection - Support 3+1 parallel redundancy, current sharing
- Built-in active PFC function
- Operating up to 5000m altitude
- Fan speed automatic adjustable
- Safety according to IEC62368, ES/EN60601
Downloads
Additional Information
| Device | Power Supply |
| Type | Metal Case | Switch Mode |
| Input Voltage | 90 ~ 264VAC/120 - 430VDC |
| Output | 48VDC @ 21A + 5V @ 2A |
| Size | 190.0 x 127.0 x 40.5 mm |
