LM50-20B15
Metal Case Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 15VDC @ 3,4A. Terminal Block Term. 4KVAC Isolation (LRS-50-15) (Metal Case 15V - 3,4A)
Small Outline Switch Mode Power Supply
Overview
LM50-20Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features universal AC input and at the same time accepts
DC input voltage, cost-effective, low no load power consumption, high efficiency, high reliability and double or reinforced insulation. These
converters offer excellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, IEC/EN60335, GB4943,
IEC/EN61558 standards and they are widely used in areas of industrial, LED, street light control, electricity, security, telecommunications,
smart home etc.
Feature
- Universal 85 - 264VAC or 120 - 370VDCinput voltage
- Accepts AC or DC input (dual-use of sameterminal)
- Operating ambient temperature range: -30℃to+70℃
- Low standby power consumption, highefficiency
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltageprotection
- Over-voltage class Ⅲ (designed to meet EN61558)
- Operating altitude up to 5000m
Downloads
Additional Information
| Device | Power Supply |
| Type | Small | Outline | Switch Mode |
| Size | 99.00 x 82.00 x 30.00 mm |
$5.68
Original: $18.92
-70%LM50-20B15—
$18.92
$5.68Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Metal Case Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 15VDC @ 3,4A. Terminal Block Term. 4KVAC Isolation (LRS-50-15) (Metal Case 15V - 3,4A)
Small Outline Switch Mode Power Supply
Overview
LM50-20Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features universal AC input and at the same time accepts
DC input voltage, cost-effective, low no load power consumption, high efficiency, high reliability and double or reinforced insulation. These
converters offer excellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, IEC/EN60335, GB4943,
IEC/EN61558 standards and they are widely used in areas of industrial, LED, street light control, electricity, security, telecommunications,
smart home etc.
Feature
- Universal 85 - 264VAC or 120 - 370VDCinput voltage
- Accepts AC or DC input (dual-use of sameterminal)
- Operating ambient temperature range: -30℃to+70℃
- Low standby power consumption, highefficiency
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltageprotection
- Over-voltage class Ⅲ (designed to meet EN61558)
- Operating altitude up to 5000m
Downloads
Additional Information
| Device | Power Supply |
| Type | Small | Outline | Switch Mode |
| Size | 99.00 x 82.00 x 30.00 mm |
