LM200-10B48
Metal Case Small Outline Switch Mode Power Supply Input: 180 ~ 264VAC (Switch)/240 - 370VDC. Output 48VDC @ 4,4A. Terminal Block Term.
Small Outline Switch Mode Power Supply
Feature
- Selectable AC input range: 90 - 132VAC/180- 264VAC
- DC input range: 240 - 370VDC(Switch inpositionof 230)
- Ultra low standby power consumption <0.75W@230VAC
- Operating ambient temperature range: - 30āto+70ā
- High efficiency, high reliability
- LED indicator for power on
- Output short circuit, over-current, over-voltage, over-temperature protection
- Operating altitude up to 5000mļ¬ Safety according to EN60335, EN61558
Downloads
Additional Information
| Device | Power Supply |
| Type | Small Outline | Switch Mode |
| Input Voltage | 180 ~ 264VAC (Switch)/240 - 370VDC |
| Output | 48VDC @ 4,4A |
$33.00
LM200-10B48ā
$33.00
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Metal Case Small Outline Switch Mode Power Supply Input: 180 ~ 264VAC (Switch)/240 - 370VDC. Output 48VDC @ 4,4A. Terminal Block Term.
Small Outline Switch Mode Power Supply
Feature
- Selectable AC input range: 90 - 132VAC/180- 264VAC
- DC input range: 240 - 370VDC(Switch inpositionof 230)
- Ultra low standby power consumption <0.75W@230VAC
- Operating ambient temperature range: - 30āto+70ā
- High efficiency, high reliability
- LED indicator for power on
- Output short circuit, over-current, over-voltage, over-temperature protection
- Operating altitude up to 5000mļ¬ Safety according to EN60335, EN61558
Downloads
Additional Information
| Device | Power Supply |
| Type | Small Outline | Switch Mode |
| Input Voltage | 180 ~ 264VAC (Switch)/240 - 370VDC |
| Output | 48VDC @ 4,4A |
