LIF120-10B12R2S-EX
DIN Rail Metal Case Switch Mode Power Supply with Active PFC. Input: 85 ~ 264VAC/120 - 370VDC. Output 12VDC @ 10A Hi Reliability. ATEX/Ex
Metal Case Switch Mode Power Supply
Feature
- Universal 85 - 264VAC or 120 - 370 VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +85℃
- High efficiency, high reliability
- DC OK function
- DC ON output status indicator LED
- Active PFC
- Output short circuit, over-current, over-voltage, over-temperature protection
- ATEX, IECEx increased safety type explosion-proof certification approved
- Operating altitude up to 5000m
- OVCⅡ
- Indoor use
Downloads
Additional Information
| Device | Power Supply |
| Type | Metal Case | Switch Mode |
| Input Voltage | 85 ~ 264VAC/120 - 370VDC |
| Output | 12VDC @ 10A |
| Size | W-32mm x H-110mm x D-124mm |
$23.98
Original: $79.95
-70%LIF120-10B12R2S-EX—
$79.95
$23.98Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
DIN Rail Metal Case Switch Mode Power Supply with Active PFC. Input: 85 ~ 264VAC/120 - 370VDC. Output 12VDC @ 10A Hi Reliability. ATEX/Ex
Metal Case Switch Mode Power Supply
Feature
- Universal 85 - 264VAC or 120 - 370 VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +85℃
- High efficiency, high reliability
- DC OK function
- DC ON output status indicator LED
- Active PFC
- Output short circuit, over-current, over-voltage, over-temperature protection
- ATEX, IECEx increased safety type explosion-proof certification approved
- Operating altitude up to 5000m
- OVCⅡ
- Indoor use
Downloads
Additional Information
| Device | Power Supply |
| Type | Metal Case | Switch Mode |
| Input Voltage | 85 ~ 264VAC/120 - 370VDC |
| Output | 12VDC @ 10A |
| Size | W-32mm x H-110mm x D-124mm |
