LD10-26B05A2
Encapsulated Surface Mount Switch Mode Power Supply Input: 90 ~ 528VAC/100 - 745VDC. Output 5VDC @ 2A. 4KVAC Isolation
Surface Mount Switch Mode Power Supply
Feature
- Ultra wide input voltage range: 90 - 528VAC/100 - 745VDC
- Regulated output, Low ripple & noise
- Operating temperature range: -40℃ to +70℃
- Output short circuit, over-current, over–voltage protection
- Isolation voltage: 4KVAC
- EFT /Surge: ±4KV Perf. Criteria B
- EN62368 approval
Downloads
Additional Information
| Device | Power Supply |
| Type | Surface Mount | Switch Mode |
| Input Voltage | 90 ~ 528VAC/100 - 745VDC |
| Output | 5VDC |
| Output Current | 2A |
| Size | 96.10 x 54.00 x 38.50 mm |
$8.08
Original: $26.94
-70%LD10-26B05A2—
$26.94
$8.08Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Encapsulated Surface Mount Switch Mode Power Supply Input: 90 ~ 528VAC/100 - 745VDC. Output 5VDC @ 2A. 4KVAC Isolation
Surface Mount Switch Mode Power Supply
Feature
- Ultra wide input voltage range: 90 - 528VAC/100 - 745VDC
- Regulated output, Low ripple & noise
- Operating temperature range: -40℃ to +70℃
- Output short circuit, over-current, over–voltage protection
- Isolation voltage: 4KVAC
- EFT /Surge: ±4KV Perf. Criteria B
- EN62368 approval
Downloads
Additional Information
| Device | Power Supply |
| Type | Surface Mount | Switch Mode |
| Input Voltage | 90 ~ 528VAC/100 - 745VDC |
| Output | 5VDC |
| Output Current | 2A |
| Size | 96.10 x 54.00 x 38.50 mm |
