HKD USB RS485 TTL CONVERTER FTDI
USB to RS485 TTL Serial Converter Adapter FTDI Interface FT232RL
USB to RS485 TTL Serial Converter Adapter
Features
- Support Windows98 / ME / 2000 / XP / WIN7 / Vista / Linux / Mac
- Support devices with RS485 interface : surveillance cameras, video capture device, fingerprint attendance machine, PBX, CNC machine, microcontroller, etc.
- This converter provides two way serial communications signal
- Conversion between the RS485
- To and from a personal computer USB port
- Using virtual serial COM port
- Self-powered from USB
- Standard : USB2.0 standard, backward compatible, in line with the standard RS485
- Direction control : the use of automatic data flow control, auto distinguish and control data transfer direction
- Baud : 300-9216000bps, automatically detecting the serial signal data rate
- Load capacity : support multipoint, each converter allows RS485 interface device to connect 32
- Interface Protection: TVS tube protection, USB self-recovery protection
- Size : Approx. 76 x 18.5 x 16mm
Additional Information
| Device | Serial Converter Adapter |
| Type | USB to RS485 TTL |
