HKD PWM DC MOTOR CONT 10A 12-40V
10A Speed Controller/PWM Speed Controller/12V-40V 10A Speed Controller
12V-40V 10A Speed Controller
Specifications
- The input supply voltage range is 12V-40VDC.
- Power: 0.01-400w
- frequency is 13khz
- PWM pulse width speed range: 10% - 100%
- Incorporate a 10A fuse, and with reverse connection power supply protection function.
- Product specification:
- Size: 60 * 55 * 28mm, the distance between the four positioning holes and the edge of the plate is 5mm, and the diameter of the positioning hole is 3.2mm.
- Weight: 69g
- On board 10A fuse with standard size of 5 * 20mm
Additional Information
| Device | Speed Controller |
