HFD17-24-ZH-3N
Low Power Sub-Mini Sealed Relay Form 1C (1c/o) 5 Pin 24VDC 2800 Ohm Coil 3A 250VAC/30VDC Max 8A/30VDC N4100F-2CHS3-24Vr
Overview
Features
- Low coil power consumption.
- High sensitivity.
- Small size, light weight.
- PC board mounting.
- Suitable for automation facilities, telecommunication equipment, household electrical appliance, wireless radio remote control, sound control toys application etc.
Specification
| Contact Form | Form 1C |
| Size | 15.5 × 11 × 11.5 |
| Termination | PCB |
| Coil Rated Voltage | 24V |
| AC/DC Voltage | DC |
| Max. Switching Current | 5A |
| Electrical Rating | 30VDC/125VAC |
| Coil Power | 0.2W Power |
| Coil Resistance | 2880Ω |
| Approvals | UL | CUR |
| Contact Material | Ag | AgNi | AgCdO |
| No. of Pins | 5 Pin(s) |
