HF115FP-024-2Z4B
High Power Mini Flux Proof Transparent Relay w/LED Indicator & Test Clip Form 2C (2c/o) 5mm Contact Spacing 24VDC 1440 Ohm Coil 8A 250VAC (440VAC Max.)
High Power Mini Flux Proof Transparent Relay w/LED Indicator & Test Clip
Features
- 1 pole 16A, 2 pole 8A , 1 CO & 2 CO contacts
- 5kV dielectric, Creepage distance 8 mm (coil to contacts)
- Meeting VDE 0700, 0631 reinforce insulation
- DC/AC coil type relay , Coil power 400mW / 0.75VA
- Manual test device
- Type with mechanical indicator / electrical indicator
- Sockets available
Downloads
Additional Information
| Device | Relay |
| Type | High Power | Mini Flux Proof |
| Contact Form | Form 2C |
| Coil Rated Voltage | 24V |
| Max. Switching Current | 8A |
| Coil Resistance | 1440Ω |
$1.66
Original: $5.52
-70%HF115FP-024-2Z4B—
$5.52
$1.66Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
High Power Mini Flux Proof Transparent Relay w/LED Indicator & Test Clip Form 2C (2c/o) 5mm Contact Spacing 24VDC 1440 Ohm Coil 8A 250VAC (440VAC Max.)
High Power Mini Flux Proof Transparent Relay w/LED Indicator & Test Clip
Features
- 1 pole 16A, 2 pole 8A , 1 CO & 2 CO contacts
- 5kV dielectric, Creepage distance 8 mm (coil to contacts)
- Meeting VDE 0700, 0631 reinforce insulation
- DC/AC coil type relay , Coil power 400mW / 0.75VA
- Manual test device
- Type with mechanical indicator / electrical indicator
- Sockets available
Downloads
Additional Information
| Device | Relay |
| Type | High Power | Mini Flux Proof |
| Contact Form | Form 2C |
| Coil Rated Voltage | 24V |
| Max. Switching Current | 8A |
| Coil Resistance | 1440Ω |
