FCP22R-1K
1K00 Pot Single Turn 1W 6,00mm Shaft
1K00 Pot Single Turn 1W 6,00mm Shaft
Downloads
Additional Information
| Model | FCP22R |
| Device | Pot |
| Type | 1K00 | Single Turn | 1W | 6,00mm | Shaft |
| Size | 6,00mm |
| Termination | Turret type |
| Power Rating | 1W |
| Resistance Value | 1000Ω |
| Tolerance | ±20% |
| Tolerance Code | M |
| Element Type | Conductive Plastic |
| No. of Turns | 1 Turn 360° |
| Mechanical Life | 10 000 000 Cycles |
| Mounting Style | Bush Mount |
| Shaft Diameter | 6,00mm |
| Shaft Type | Slotted Stainless Steel |
