• Connector design : Female cable connector
• Type standard : DIN EN 61076-2-101
• Version : Connector socket straight
• Connector locking system : screw
• Termination : screw clamp
• Degree of protection : IP67
• Cross-sectional area : max. 0.75 mm² / AWG 18
• Cable outlet : 6.0-8.0 mm
• Temperature range from/to : -40 °C / 85 °C
• Mechanical operation : > 100 Mating cycles
• Weight (g) : 45.07
• Customs tariff number : 85369010
• Country of Origin : HU

Electrical parameters

• Rated voltage : 250 V
• Rated impulse voltage : 2500 V
• Rated current : 4.0 A
• Insulation resistance : ≥ 10¹⁰ Ω
• Pollution degree : 3
• Transmission rate : CAT 5
• Overvoltage category : II
• Insulating material group : III
• EMC compliance : shieldable
• Shield connection : Shielding ring

1. Datasheet - 99-3730-810-04
