99-0639-29-05
Circular Connector M12 L COD Cable Male Straight 5 Pole(4+FE) Screw Lock 13mm Cable Entry IP67, UL Approved Max. 16A /63VDC
M12 L COD Cable Circular Connector
Specifications
| Connector design | Male cable connector |
| Type standard | DIN EN IEC 61076-2-111:2018-10;VDE 0687-76-2-111:2018-10 |
| Coding | L-coded |
| Version | Connector pin straight |
| Connector locking system | screw |
| Termination | screw clamp |
| Degree of protection | IP67 |
| Connection cross-section | max. 1.50 mm² with ferrule / max. 2.50 mm² without ferrule / AWG 16 with wire-end ferrule / AWG 14 without wire-end ferrule |
| Cable outlet | 8.0-13.0 mm |
| Temperature range from/to | -40 °C / 105 °C |
| Mechanical operation | > 100 Mating cycles |
| Weight (g) | 42.89 |
| Customs tariff number | 85369010 |
| Country of Origin | DE |
Electrical parameters
| Rated voltage | 63 V |
| Rated impulse voltage | 1500 V |
| Rated current | 12 A (at 1.5 mm²/AWG 16) / 16 A (at 2.5 mm²/AWG 14) |
| Insulation resistance | > 1010 Ω |
| Pollution degree | 3 |
| Overvoltage category | III |
| Insulating material group | I |
| EMC compliance | unshielded |
Material
| Housing material | PA |
| Contact body material | PA (UL94 V-0) |
| Contact material | CuZn (brass) |
| Contact plating | Au (gold) |
| REACH SVHC | CAS 7439-92-1 (Lead) |
Downloads
Additional Information
| Device | Connector |
| Type | M12 | L COD | Cable | Circular |
