74AC11008

Product image 1

74AC11008

Quadruple 2-Input Positive-AND Gates 16PIN DIP

Specifications

Electrical Characteristics

  • Supply voltage (V_CC): 3 V to 5.5 V
  • Quiescent current: ~4 µA typical
  • Output drive: ±24 mA (able to source or sink up to ~24 mA at HIGH/LOW)
  • Input thresholds:
  • LOW input recognized from ~0.9 V to 1.65 V
  • HIGH input from ~2.1 V to 3.85 V
$0.44

Original: $1.47

-70%
74AC11008—

$1.47

$0.44

Product Information

Shipping & Returns

Description

Quadruple 2-Input Positive-AND Gates 16PIN DIP

Specifications

Electrical Characteristics

  • Supply voltage (V_CC): 3 V to 5.5 V
  • Quiescent current: ~4 µA typical
  • Output drive: ±24 mA (able to source or sink up to ~24 mA at HIGH/LOW)
  • Input thresholds:
  • LOW input recognized from ~0.9 V to 1.65 V
  • HIGH input from ~2.1 V to 3.85 V
