• Supply Voltage (Vcc): 4.75 V – 5.25 V
• Absolute Max Vcc: ~7 V
• Input Voltage Range: –0.5 V to Vcc
• Logic HIGH (VIH): ≥ 2.0 V
• Logic LOW (VIL): ≤ 0.8 V
• Output HIGH (VOH): ≥ 2.4 V
• Output LOW (VOL): ≤ 0.4 V
• Propagation Delay: ~20–40 ns typical
• Power Dissipation: ~50 mW typical
• Operating Temperature: 0 °C to 70 °C

• Dual independent one-shot circuits
• Non-retriggerable operation
• Adjustable pulse width via external RC
• Complementary outputs
• Noise-immune triggering
• TTL compatible

Typical Applications

• Pulse generation
• Timing delays
• Switch debouncing
• Pulse shaping
• Missing-pulse detection
• Digital timing control systems
