631H
Apem Hi Quality/ Reliability Metal Lever Toggle Switch Single Pole SPST On -Off. Screw Terminal. 15A/250VAC(12VDC) 10A/24VDC VDE Approved
Hi Quality/ Reliability Metal Lever Toggle Switch
Specifications
Electrical Specifications
- Max. Current/Voltage Ratings : see tables below
- Peak Current : 30A max. during 1/2 sine, 250VAC
- Initial Contact Resistance : 10 mΩ max.
- Insulation Resistance : 1.000 MΩ min. at 500VDC
- Dielectric Strength :
- 2.000 Vrms 50 Hz min. between terminals
- 2.500 Vrms 50 Hz min. between terminals and frame
- Electrical life : 10.000 cycles at full load
General Specifications
- Torque : 1,50 Nm (1.10 Ft.lb) max. applied to nut
- Panel Thickness : 4,5 mm (.177) max. between 2 nuts
- Operating Temperature : -20°C to +55°C
Downloads
Additional Information
| Device | Switch |
| Type | Hi Quality/ Reliability | Metal Lever | Toggle |
| Transition Style | Momentary |
| Actuator Style | Toggle |
| Termination | Screw |
| Switch Circuit | SP ON-OFF |
| Electrical Rating | 15A 250VAC |
| No.of Poles/Pins | 1 |
$2.74
Original: $9.12
-70%631H—
$9.12
$2.74Product Information
