1594BWBK
Polystyrene Enclosure 81X56X40 Grey Water-Tight
Heavy Duty Enclosure
Feature(s)
- Rugged electronic instrument enclosures, ideally suited for mounting printed circuit boards.
- Heavy duty, thick wall design with an average wall thickness of .13” (3.3 mm).
- Also suited for vertical or horizontal mounting of printed circuit boards (using optional P.C. card guides - see accessories below).
- Molded from flame retardant ABS plastic (material carries a UL flammability rating of 94V-0).
- Interior of each enclosure part is specially masked and sprayed with an RFI/EMI copper conductive coating (see photo above).
- Coating manufacturer specifies an attenuation of more than 75 db from 1 Mhz. to 1 Ghz.
- Designed to meet IP54.
- Countersunk lid is secured with four M3 x 0.5 - 0.71” (18 mm) long, Philips machine screws threaded into integral brass bushings. Perfect for applications with repetitive assembly and disassembly are required.
- Stocked in black with matte textured finish.
Specifications
| Size L x W x H | 3.2 in x 2.2 in x 1.1 in (81 mm x 56 mm x 28 mm) |
|---|---|
| Shipping Weight | 0.17 lbs (0.08 kg) |
| UNSPSC | 39121301 |
| UPC | 623980564227 |
| Packaging Type | shrink wrap |
| Material | ABS Plastic |
| Color | Black |
| Flame Rating | UL94 V-0 |
| IP Rating | IP65 |
| Product Category | Enclosures |
| Type | Thick wall, water-tight |
Downloads
Additional Information
| Device | Enclosure |
| Type | Heavy Duty |
