142M4D15010
Cordset Shielded M12 D-Coded Male Straight 4 Pole – RJ45 Plug AWG 26 (4 x 1) - 1m Pure Cable
M12 D-Coded Male Straight 4 Pole
Feature(s)
- Shielded M12 to RJ45 Ethernet Connection Line
- Cat.5, 4-pole, D-coded (IEC 61076-2-101)
- M12 Connector, Straight to RJ45 Connector
- Connectors Over Molded
- Stranded Wires 2x2xAWG22/7
- Overall Shield Tinned Copper Braid
- Pin Assignment Per Profinet
- Green Cable, PUR
Downloads
Additional Information
| Device | Connector |
| Type | M12 | D-Coded | Male | Straight | 4 Pole |
